Specifications
| Discharge height: | up to 3.5 m |
|---|---|
| Channel width: | 500 – 2000 mm |
| Water level: | up to 2.3 m impoundage |
| Standard slot width: | 3 and 6 mm |
Huber Fine Screen STEP SCREEN® SSF
- for high separation efficiencies
- for any flow rate
- easy and reliable screenings transport
The variable installation angle ensures
- Optimal adjustment to individual hydraulic conditions, such as limited upstream levels due to preceding pumping stations
- Operating reliability due to tailor-made layout
Benefits:
Function principle:
- Lifting of screenings at bottom level
- Gentle and complete screenings transport due to the counter-current principle
Flow rate:
High capacity; the flow passes the screen surface only once
Separation efficiency:
Very high separation efficiency due to the narrow slot width and the produced screenings carpet.
Cleaning:
Self-cleaning effect due to movable lamellas (no spray water required, no brushes)
Operational stability:
Reduced susceptibility to grit, gravel and stones due to the bottom step washing system.
Pivoted screen:
Without the need to remove the subsequent wash press or transport unit.
Protection against corrosion:
Completely manufactured from stainless steel and acid-treated in a pickling bath.
