Specifications
| Screen basket: | 780 to 3000 mm |
|---|---|
| Throughput capacity: | up to 3500 m3/h |
| Mesh size: | 0.75 mm |
ROTAMAT® Membrane Screen RoMem
- Removal of fibres and hair
- Increased operational stability of membrane bioreactors
- COD/BOD reduction in river or sea outfalls
- Reduced load on the biological treatment system of sewage treatment plants without preliminary treatment
The ROTAMAT® Membrane Screen is a very fine screen and provides a large screening surface due to its drumshaped screen basket and installation angle. The headloss of the screen is therefore low even with higher flow rates.
Benefits:
- Protection of downstream equipment, e.g. MBR plants, through removal of fibres, hair and other disturbing material
- Reduced load on downstream biological treatment systems due to removal of AFS, COD and BOD
- Fine screening of large wastewater volumes in a gravity line
- Low headloss due to the use of square mesh
- Extensive reduction of COD and BOD for river and sea outfalls
- High efficiency through combination of screening, transport, dewatering, compaction and discharge of
screenings in one compact unit with one drive - High-pressure washing at 120 bar eliminates blocking.
- Available in a stainless steel tank or for channel installation
