Specifications
| Troughput capacity: | up to 200m³/h |
|---|
HUBER Sludgecleaner STRAINPRESS®
Continuous screening, dewatering and transport of coarse material in one operation
Removal of coarse material from municipal sludge and industrial process water
the STRAINPRESS® is used for liquid sludge screening or filtration of service or process water under pressure.
Examples for coarse material separation from:
- Primary sludge
- Secondary sludge
- Mixed sludge
- Septic sludge
- Floating sludge
- Grease sludge
- Digested sludge
- Production wastewater and industrial sludges
- Circulation and process water
Benefits:
- Pressure-fed (inline) system for process water and any type of sludge including highly viscous and grease containing sludge
- Increases the operating reliability of downstream sludge treatment systems, such as thickening,
disinfection, stabilisation, dewatering, drying, and reduces maintenance requirements - For various applications perforations of 2 to 10 mm, different screw geometries and different material qualities are available
- Reliable cleaning of the screen without any wash water
- pressure-dependent control of the screw shaft combined with the pressure cone regulation system
allows for unattended automatic operation even with varying flow rates - Dewatering of separated coarse material to approx. 40% DR
